Flyover - 1
- TOTAL SPAN/ LENGTH:
- Main:1x25 + 1x80 + 16x25 + 1x28.6 +1x21.4 + 2x30 + 1x25 = 640.0m
- DECK WIDTH:1x16m & 1x12.5m
- PSC Girder (Pre Tensioned - Precast)
- Twin Circular Pier & Single Circular Pier
- Pile Foundation
- TOTAL SPAN/ LENGTH:
- Right Arm: 43.189 + 47.5 + 30 + 26 + 20 + 30 + 28 + 15 + 25 + 45 + 30 + 45 = 384.69m
- DECK WIDTH:2x16.15m & 2x11.9m
- 5 / 4 Girder system with Indirect Support
- Twin Circular Pier & Single Circular Pier
- Pile Foundation (4 / 6 / 8 Pile group)
Flyover - 2
- TOTAL SPAN/ LENGTH:
- Main:2x27.45 = 54.9m
- PSC Girder (Pre Tensioned - Precast)
- Twin Square Pier & Single Square Pier
- 5 / 4 Girder system with Indirect Support
- Pile Foundation
